上柴股份500KW柴油發電機組
首頁>>產品展示
聯系我們

聯系人:李經理

銷售部: 138-6360-1639

QQ:2397099983

E-mail:fengmaodl@163.com

網址:http://mnyk.com.cn

地址:濰坊市濰城區騰飛路臥龍街


上柴股份500KW柴油發電機組


上柴股份600KW柴油發電機組

上柴股份600KW柴油發電機組

該系列發電機組采用上海柴油機股份有限公司生產H系列、D系列、E系列、G系列、W系列電站柴油機作為動力,配置名牌發電機。機組具有調壓精度高、動態性能好、電壓波形畸變小、效率高、工作可靠、使用壽命長、經濟性能好等特點。機組配置全套免維護蓄電池啟動系統,用戶只需注入機油和防凍液、接通開關就可以啟動機組,輸出電力,提高了使用的便捷性。

This series of generator sets are made by Shanghai diesel engine co., LTD., which produces series H series, D series, E series, G series and W series power station diesel engines as power, and equipped with famous brand generator. The unit has the characteristics of high pressure regulating precision, good dynamic performance, low voltage waveform distortion, high efficiency, reliable work, long service life and good economic performance. The unit is equipped with a full set of no-maintenance battery startup system. The user can start the unit with the injection of oil and anti-freeze liquid and switch on the switch, so as to output power and improve the convenience of use.

機組型號輸出功率KW輸出功率KVA電流A柴油機型號缸數缸徑*行程mm潤滑油容量L油耗g/kw.g機組外形尺寸L×W×H機組重量kg
FM50GF5062.590SC4H95D24135*140252322200*800*13801500
FM75GF7593.75135SC4H15D24135*150252252300*900*13001600
FM100GF100125180SC4H160D24105*124131932500*900*15002000
FM120GF120150216SC4H180D24135*150282262600*900*15502250
FM150GF150187.5270SC7H230D26105*12417.51992600*900*15502300
FM170GF170212.5306SC7H250D26114*135191982600*900*16002400
FM180GF180225324SC8D280D26114*144191982600*1050*16002400
FM200GF200250360SC9D310D26114*144191982600*1050*16002600
FM220GF220275396SC9D340D26135*150332253000*1280*16502650
FM250GF250312.5450SC13G355D26135*150332253000*1280*16502800
FM250GF250312.5450SC13G420D26135*150332253000*1280*16502800
FM300GF300375540SC12E460D26128*153371923000*1280*17003450
FM320GF320400576SC15G500D26135*165332003200*1350*18503500
FM350GF350437.5630SC15G500D26135*165332023200*1350*19003500
FM400GF400500720SC25G610D212135*150652023400*1500*19504200
FM450GF450562.5810SD25G690D212135*155652023500*1500*19504500
FM500GF500625900SC27G755D212135*155652023500*1500*20004800
FM550GF550687.5990SC27G830D212135*155652023600*1600*20005000
FM600GF6007501080SC27G900D212135*155652023650*1600*20005050
FM660GF6608251188SC33W990D26180*215752054400*1700*21505200
FM800GF80010001440SC33W1150D26180*215752054800*1800*22506500
1.以上技術參數轉速為1500RPM,頻率50HZ,額定電壓400/230V,功率因數0.8,接線方式為三相四線。
2.發電機可以根據客戶需求,選用上海斯坦福、上海馬拉松、無錫斯坦福等知名品牌。
3.60HZ發電機組可以根據客戶的特殊需要定制。
4.本參數表僅供參考,如有更改恕不另行通知。
標準配置 Standard equipment:
發動機 diesel engine
發電機 alternator
散熱器 water cooled radiator
工業消音器 、波紋管 industrial silencer and flexible exhaust hose
啟動免維護蓄電池及蓄電池
電池連接線 maintenance-free lead-acid starting batteries and battery connect wires
輸出斷路器 output circuit breaker
智能控制屏 digital control panel
鋼式底架 steel base frame
可選配置 Optional equipment
低噪音靜音機箱 Low noise silent case
四輪移動拖車電站 Four-wheel mobile trailer power station
自啟動、自轉換
開關柜 Self - start, self - conversion switch cabinet
自動并機控制系統 automatic parallel operation control system
電熱式水套加熱器 electrothermal water jacket heater
